Distributed task execution, a cache you host, exact restores

Distributed task execution (DTE) spreads one vx run over workers your own CI starts. There is no vendor cloud: the relay between them is a server you host.

This release is breaking. Read the breaking changes first.

Spread one run over your own CI workers

flowchart LR
  O["your CI job: vx run"] -- "start, cancel" --> API[CI API]
  API --> W1["worker small#1"]
  API --> W2["worker small#2"]
  O <-- "orders, status" --> R(("relay: stores nothing"))
  R <--> W1
  R <--> W2
  W1 -- "outputs by key" --> C[(remote cache)]
  W2 --> C
  C -- "restore" --> O

Your CI job’s vx run starts workers through your CI’s API and hands them the tasks the cache cannot answer.

Workers save outputs to your remote cache, and the run restores them. Each side signs in with its CI job’s OIDC token, so no secret is stored.

.vx/workspace.ts

import { defineWorkspace } from '@vzn/vx/config'
import { dte, github } from '@vzn/vx-dte'

export default defineWorkspace({
  plugins: [
    dte({
      relay: 'https://relay.example.com',
      workers: { small: { max: 8, cpu: 4, memory: '16GB' } },
      adapter: github(),
    }),
  ],
})

workers names the sizes the run may start. gitlab() starts workers as GitLab pipelines.

$ vx dte init
vx dte init: wrote .github/workflows/ci.yml
vx dte init: wrote .github/workflows/vx-worker.yml

Next:
  1. Let these workflows use the relay at https://relay.example.com: set its ALLOW.
     Its ALLOW (a plain var, no secret): https://token.actions.githubusercontent.com:acme/app:ci.yml https://token.actions.githubusercontent.com:acme/app:vx-worker.yml
  2. A remote cache the run and the workers share: workers hand back outputs only through it. https://vznjs.github.io/vx/docs/remote-cache/
  3. Commit .github/workflows/ci.yml, .github/workflows/vx-worker.yml, .vx/workspace.ts and the lock (vx lock), and push.
  How a run spreads over workers: https://vznjs.github.io/vx/docs/distributed-task-execution/

vx dte init writes both workflows and prints what is left.

Watch a run on your machine

local() starts each worker in its own git worktree, with no CI:

dte({ workers: { small: { max: 3, cpu: 1, memory: '2GB' } }, adapter: local() })

$ VX_DTE_RUN=$(uuidgen) vx run test --all --force
 ⏺︎   3.01s success miss     ui#test · small#2
 ⏺︎   3.41s success miss     web#test · small#1
 ⏺︎   2.21s success miss     billing#test · small#1
 ⏺︎   2.61s success miss     search#test · small#2
 ⏺︎   1.41s success miss     api#test · small#2
 ⏺︎   1.81s success miss     auth#test · small#1

  workers   small#1  stopped  3 done · warm-up 0.1s
                     declared 1c/2G · actual 4c/14G
                     online 7.5s · busy 7.5s · idle 0.0s
                     cpu peak 2.0 · used avg 1.0 cores · machine avg 2.0 · booked avg 1.0 · cpu utilization 98%
                     sent 3 messages · 4 KB, received 3 messages · 617 B
            small#2  left     3 done · warm-up 0.2s
                     declared 1c/2G · actual 4c/14G
                     online 7.1s · busy 7.1s · idle 0.0s
                     cpu peak 2.0 · used avg 1.0 cores · machine avg 2.0 · booked avg 1.0 · cpu utilization 99%
                     sent 3 messages · 4 KB, received 3 messages · 621 B
            probe    at 0.0s: 6 tasks left to run, 0 known misses
            asked    2 at 0.0s for 6 tasks (6 measured), plan 27.4s
            ideal    5.0s: each task as long as it took, placed perfectly
            total    cpu utilization 98%

  time      7.65s · max 3.41s · avg 2.41s · min 1.41s

The footer shows each worker’s time and CPU use.

A relay restart does not lose the run

The relay stores nothing, so a restart loses no state. The run and its workers join again within 4 s while tasks keep running.

See Distributed task execution.

Task timings from a server you host

.vx/workspace.ts

import { defineWorkspace } from '@vzn/vx/config'
import { vxHistory } from '@vzn/vx-history'

export default defineWorkspace({
  plugins: [
    vxHistory({
      url: 'https://history.example.com',
      issuer: 'https://token.actions.githubusercontent.com',
      repository: 'acme/app',
    }),
  ],
})

@vzn/vx-history-server keeps each task’s duration, cores and peak memory. A fresh CI runner reads them, starts the longest work first, and DTE plans its workers by them.

$ vx last --live
run 01a18750-df8a-74a5-9878-0f0df6bdf9e5 — running 2.52s
  $ vx run test --all --force
  3 running · 3 ended · 0 waiting

  running  search#test   2.51s
  running  ui#test       1.09s
  running  web#test      689ms
  success  api#test      1.41s
  success  auth#test     1.81s
  success  billing#test  2.21s

$ vx last --sql "SELECT project, COUNT(*) AS runs, MAX(duration_ms) AS slowest_ms FROM runs GROUP BY project ORDER BY slowest_ms DESC LIMIT 3"
project  runs  slowest_ms
web      2     3411
ui       2     3009
search   2     2609

vx last --live shows a running run; --sql queries the history.

Host the remote cache yourself

flowchart LR
  J[CI job] -- "its own OIDC token" --> S[vx-cache-server]
  S -- "ALLOW names the workflow" --> B[(one bucket: R2 or S3)]
  P[pull request] -- "writes only its own ref" --> S

@vzn/vx-cache-server keeps the cache in one bucket you own.

.vx/workspace.ts

import { defineWorkspace } from '@vzn/vx/config'
import { vxCache } from '@vzn/vx-cache'

export default defineWorkspace({
  plugins: [
    vxCache({
      url: 'https://cache.example.com',
      issuer: 'https://token.actions.githubusercontent.com',
      repository: 'acme/app',
    }),
  ],
})

CI fills it, and a laptop reads the hit back:

# CI job on main
$ vx run build
└─ //#build ── (12ms) success
            remote 1↑ 270 B

# laptop, empty local cache
$ vx run build
┌─ //#build > $ mkdir -p dist && cp src/*.ts dist/
└─ //#build ── (30ms) restored-remote
            remote 1↓ 270 B

See Remote cache.

A hit puts back exactly what ran

A restore that loosens a directory’s mode would expose what the task kept private:

$ rm -rf dist
$ vx run build
┌─ //#build > $ mkdir -p dist/keys && cp src/*.ts dist/keys/ && chmod 700 dist/keys
└─ //#build ── (11ms) restored-local
$ ls -ld dist/keys
drwx------ 2 root root 4096 Oct 29 08:40 dist/keys

Now a hit gives each output directory the mode the task left.

A lockfile change re-runs what it reaches

$ vx run build --affected=HEAD~1 --dry
would run:
  ∅  app#build  no-cache (would exec)     6cea8c21
                affected: packages/lib/index.js changed (an input), via lib#build
  ∅  lib#build  no-cache (would exec)     ec139120
                affected: packages/lib/index.js changed (an input)

2 task(s) planned, 2 no-cache.

app never names lib, but the root package.json installs it, so app re-runs too.

See Lockfiles.

A config mistake is refused with its fix

A glob that matches less than you meant replays a stale hit, so vx refuses it:

$ vx lock
✗ vx lock  lock not written

  vx.config.ts:6:17
  tasks.build.inputs.files: "src/**.ts" glues ** to other text in one path segment, which vx's glob engine reads as one *, a single directory level. Write "src/**/*.ts" for every depth, or "src/*.ts" for one level.

How to update

vx upgrade

Breaking changes

Every cached task misses once (vx-cache-v51, schema v49). baseBranch: 'origin/main' and a 5M duration are refused.

Before	Now
--dry-run, --dry=text	--dry, --dry=pretty
@vzn/vx-schedule-history, scheduleHistoryPlugin()	@vzn/vx-history, vxHistory()
defaultBranch	baseBranch
history through the remote cache	a history server, vxHistory({ url })
turboCache(), nxCache() options	url and token
VX_REAPI_* variables	reapi() options
github({ checks }), otel({ post })	removed
RunResult.signal a string	a string or a number
FingerprintClaim.extraFiles	takes a ctx

See also Upgrading.
